Welded tubes and seamless tubes are two common types of cylindrical hollow sections used in various industries, each offering distinct advantages and limitations based on their manufacturing processes and intended applications.
1.The difference between welded tubes and seamless tubes
Welded Tubes
(1)Manufacturing Process
Welded tubes are produced by welding together flat or coiled steel strips to form a cylindrical shape. The welding process can be performed using various techniques such as high-frequency induction welding, submerged arc welding, or electric resistance welding.Seamless tubes are produced by extruding a solid billet through a piercing rod to create a hollow tube without the need for welding. This process results in a homogeneous structure with consistent mechanical properties throughout the tube.
(2)Advantages
Welded tubes
①Cost-Effective
Welded tubes are generally more cost-effective to produce compared to seamless tubes, making them suitable for applications where cost is a significant factor.
②Availability in Large Diameters
Welded tubes can be manufactured in larger diameters and wall thicknesses, making them well-suited for structural and industrial applications that require large-diameter tubing.
Seamless tubes
①Superior Strength
Seamless tubes offer excellent strength and integrity due to the absence of weld seams, making them ideal for high-pressure and critical applications such as hydraulic systems and precision instrumentation.
②Enhanced Corrosion Resistance
The lack of weld seams minimizes the risk of corrosion at the joints, contributing to improved corrosion resistance in harsh environments.
(3)Limitations
Welded tubes
①Weld Seam
The welded joint in the tube may create a potential weak point, especially in high-pressure or corrosive environments, requiring additional quality control measures during production.
②Surface Finish
Welded tubes may exhibit a visible seam along the length of the tube, which can affect aesthetics and surface smoothness in certain applications.
Seamless tubes
①Production Complexity
The manufacturing process for seamless tubes involves complex and specialized equipment, leading to higher production costs compared to welded tubes.
②Limited Sizes
Seamless tubes are typically available in smaller diameters and wall thicknesses compared to welded tubes, which may restrict their use in certain industrial and structural applications.
(4)Applications
①Welded Tubes
Commonly used in structural frameworks, automotive components, construction materials, and low to medium-pressure fluid transmission systems where cost efficiency and availability in large sizes are key factors.
②Seamless Tubes
Preferred for applications requiring high-pressure resistance, precise dimensional tolerances, superior corrosion resistance, and reliability in critical environments, such as oil and gas exploration, aerospace components, heat exchangers, and high-performance machinery.
2.Storage method of welded tubes and seamless tubes
The storage method for welded tubes and seamless tubes is an important consideration to maintain their quality and integrity. Here are some general guidelines for the storage of both types of tubes:
(1)Protection from Corrosion
Regardless of the type of tube, it's essential to store them in a dry environment to prevent corrosion. Moisture can lead to rust and degradation of the tubes, impacting their structural integrity. Using climate-controlled storage facilities or covering the tubes with moisture-resistant materials can help prevent corrosion.
(2)Support and Stacking
When storing tubes, ensure that they are adequately supported to prevent deformation or bending. Avoid stacking heavy objects on top of the tubes, as this can cause distortion or damage, particularly for seamless tubes, which may be more susceptible to deformation due to their uniform structure.
(3)Separation and Labeling
Keep different sizes, grades, or specifications of tubes separated and clearly labeled to avoid confusion during retri. This practice helps to maintain organization and prevents mix-ups that could lead to incorrect usage of the tubes.
(4)Protection from Physical Damage
Protect the tubes from physical damage by storing them away from high-traffic areas, heavy machinery, or potential impact hazards. Using protective barriers or racks can help safeguard the tubes from accidental damage.
(5)Ventilation and Air Circulation
Ensure adequate ventilation and air circulation in the storage area to prevent the buildup of moisture or condensation, which can contribute to corrosion. Proper airflow can also help maintain a consistent temperature within the storage environment.
(6)Handling and Transportation
When moving the tubes to and from storage, use appropriate lifting and handling equipment to minimize the risk of dents, scratches, or other forms of mechanical damage.
By following these storage guidelines, you can help preserve the quality and condition of both welded and seamless tubes, ensuring that they remain fit for their intended use when retrieved from storage.
3.Anticorrosion of welded tubes and seamless tubes
Both welded tubes and seamless tubes can be susceptible to corrosion, so it's essential to consider anticorrosion measures for both types of tubing. Here are some common methods for protecting welded and seamless tubes from corrosion:
(1)Coating and Painting
Applying protective coatings or paints to the outer surface of the tubes can provide a barrier against moisture and corrosive elements. Various coating materials such as epoxy, polyethylene, or zinc-based compounds can be used based on the specific environmental conditions the tubes will be exposed to.
(2)Galvanization
Galvanizing involves coating the tubes with a layer of zinc to provide corrosion resistance. This method is particularly effective for protecting steel tubes from rust and corrosion in harsh environments or when the tubes will be in contact with corrosive substances.
(3)Cathodic Protection
Cathodic protection involves using sacrificial anodes or impressed current systems to protect the tubes from corrosion. By creating a galvanic cell, the process directs corrosion away from the tubes, preserving their integrity.
(4)Corrosion Inhibitors
Application of corrosion inhibitors directly to the internal surfaces of the tubes can help mitigate corrosion caused by exposure to aggressive fluids or gases. These inhibitors form a protective layer that prevents corrosive substances from coming into contact with the tube material.
(5)Controlled Atmosphere Storage
When the tubes are not in use, storing them in a controlled atmosphere environment, such as a dry, low-oxygen space, can significantly reduce the risk of corrosion over time.
(6)Proper Handling and Installation
Implementing proper handling and installation practices can also contribute to the long-term corrosion resistance of both welded and seamless tubes. Avoiding damage during transportation and ensuring that the tubes are installed correctly can minimize the risk of corrosion at joints or vulnerable areas.
4. Pipe vs Tube
Pipe and Tube are two series of pipes with different diameters, connection methods, representation methods and scope of use. The differences between Pipe and Tube are mainly in the following five aspects:
(1) Pipe diameter
Pipe is a large diameter pipe, the diameter is generally between 15mm-1500mm (1/2in-60in). There are also pipes smaller or larger than this range, but they are rarely used. Tube is a small diameter pipe, the diameter is generally between 3mm-12mm (1/8in-1/2in).
(2) Connection methods
Pipe connection methods include flange connection, threaded connection and welding connection. In most cases, flange connection is used, and threaded connection is allowed in low-pressure situations. The tube wall of Tube is very thin, and threads are not allowed on it. After annealing, it is connected by a card sleeve.
(3) Diameter specification
Pipe uses DN (nominal diameter) to indicate the diameter specification of the pipe. The nominal diameter is neither the outer diameter nor the inner diameter of the pipe. It is a size number common to all components in the piping system (including pipes, flanges, valves, joints, etc.). Pipes with the same nominal diameter, Flanges, valves, and joints can be connected to each other regardless of whether other dimensions (outer diameter, inner diameter, wall thickness, etc.) are the same. In short, the adoption of nominal diameter simplifies and unifies the connection between pipes and fittings, which is why Pipe uses DN to represent pipe diameter.
Tube uses the outer diameter OD (outside diameter) to indicate the diameter specification of the tube. For example, 1/4 in OD Tube means a tube with an outer diameter of 1/4 inch. Because Tube uses a ferrule method to connect, this connection method focuses on the outer diameter. Pipes and fittings with the same outer diameter can be connected with ferrules. This is why Tube uses OD to represent the pipe diameter.
(4)Wall thickness
The wall thickness of Pipe is standard, generally expressed by the wall thickness serial number (English abbreviation Sch.No.-Schedule Number). Sch.No. is also called the pressure level number, from Sch.No.5 to Sch.60 pipes of different diameters or materials each have their own standard wall thickness series. In other words, pipes with the same Sch.No. but different pipe diameters or materials have different actual wall thicknesses.Tube wall thickness is expressed in its actual thickness dimension (inches or mm).
(5)Application
Pipe is widely used, and both process pipelines and public engineering pipelines use Pipe. Tube tubes are only used in the measurement pipelines of instrument systems, pneumatic signal pipelines and sample pipelines of online analytical instruments.
In summary, the choice between welded tubes and seamless tubes depends on specific application requirements, cost considerations, pressure ratings, and the need for enhanced mechanical integrity and corrosion resistance. Both types of tubes play crucial roles in diverse industries, offering distinct benefits based on their respective manufacturing processes and performance characteristics.
